Portable Inflatable Lighting System

The Portable Inflatable Emergency Lighting System is designed for ease of transportation and setup, featuring a built-in 1200VA/750 VA engine and generator (Genset) as a portable power source. It includes two blowers and a 400W metal halide lamp. The blower inflates cloth at a height of 4.5 meters from the ground level on switching on the Genset. It can illuminate an area of up to 10,000 square meters.

  • Applications for illuminating an area during and after fire fighting operation
  • For rescue operations during dark hours
  • For disaster management during dark hours

FEATURES

  • Easy to operate & handle
  • Excellent illumination with high-power Metal Halide lamps
  • The most fuel-efficient fuel engines
  • Illumination up to 10,000 sq. meters within 3 Minutes

SPECIFICATIONS

  • Height : 4.5 Metres
  • Minimum weight of the system (without fuel and storage box) : 45 Kg
  • Genset details : 4-Stroke
  • Generator rated output (VA) 230V/50Hz : 1200VA / 750 VA
  • Fuel tank capacity : 8.0 L / 3.6 L
  • Continuous operating hours : 10+ Hours / 5.5 Hours
  • Starting system : Recoil
  • Light source : 400W Metal Halide Lamp
  • Lamp light output (brightness) : 42,000 Lumens
  • Outside wind speed at which the balloon shall remain erected : 45 km/hr and 70 km/hr with stabilizing/supporting rods
  • Time for tower extension / inflation : 60 Sec
  • Time to pack (maximum deflation time including repacking time) : 4 Minutes
  • No. of air blowers of suitable rating : Two
  • Balloon height in inflated condition from the base plate : 4.5 Metres
  • Light up area (Approx.) : 10000 Sq. meters

Shapeshifter LED Light Tower

Aska Shapeshifter LED Light Tower pneumatically extendable upto 13.5 feet height,has multiple selectable power source options of generator & engine with fuel as diesel or petrol, apart from battery bank ( solar or Lithium providing more 50,000 lumens with 360 watt power consumption in flood light upto 180 degree or 360 degree. Being low weight of 45 KG easily towable and portable.)

FEATURES

  • Deployed by a single person
  • Produces minimum 50,000 lumens with 360-watt power consumption (60 watt x 6)
  • Can be used as 360° or 180° flood light
  • Produces about 30% more light than a 4×400W halogen system
  • Consumes 75% less power compared to a 4×400 halogen system
  • Multiple units can be transported in a regular car
  • Requires no prior training or certification and is simple to operate
  • Multiple units can be operated from a portable generator
  • Built for easy replacement of parts with a modular design
  • Can be used both indoors and outdoors (IP67) and is suitable for extreme temperatures
  • Safe to operate with colour-coded guidance
  • Takes up little space when stored
  • 50,000 hours LED lifespan, 2-year warranty on structural components
  • 45 kg weight for complete system
  • Integrated wheels
  • Dimmable light
  • Adjustable LED angles
  • 13.5 feet height from the ground when extended
  • Pneumatic operation with one-touch button for raising the mast
  • Adjustable leg angles
  • Genset or battery bank for power

SPECIFICATIONS

  • Total Lumens : More than 50,000
  • IP Rating for LED Lamp / Luminaire : IP 67
  • Input Voltage : 100 to 305 VAC / 50 Hz
  • Mast Operation Type : Pneumatic type with a single touch button
  • Integrated Wheels : Yes
  • Adjustable Tripod Legs : Yes
  • Weight of the Light Tower : 45 kg (without accessories)
  • Power Source : Honda EP 1000 genset runs for 9 hours on full load, lithium battery bank
  • Wind Resistance : Up to 12.5 m/s without resistance
  • Certifications : BIS approved LED luminaire & drivers. In addition, the complete product was tested by NABL approved lab

Mobile Light Towers (Splendid)

Aska Mobile light towers comprises of three main components i.e Power Source (Engine with alternator or Battery bank ), Mast with LED lights and controller having unmatched advanced technological features including ease of portability providing most economical and qualitative advantages to the users. In addition, It has high lumens covering wide viewing range including longer depth & more coverage area with sufficient intensity of light. Further, It takes full care of the safety of the complete Lighting tower including components as well as workforce deployed thereby. It is next generation exemplary product with remarkable life cycle, sustainability and green energy meeting prescribed emission norms by Ministry of Environment

FEATURES

  • 50000+ hours LED rated average life
  • Easy to operate & handle
  • Excellent illumination with high-power LED lamps
  • The most fuel-efficient diesel engines
  • Designed to withstand the harshest conditions
  • Hard hood canopy and powder coating paint to prevent corrosion
  • Easy to tow anywhere with a 13" wheel
  • Equipped with Deep Sea, the world’s No.1 engine controller designed for light towers

SPECIFICATIONS

  • Type of Lamp Fittings : Rectangular
  • Floodlights / Lamp : LED
  • Wattage : 4 No’s x 350 W
  • Total Lumens Output : 210000 Lumens
  • Lumens per Watt : 150 Lm / W
  • Light Coverage (Square Meters) : 5800 Sq m
  • Ingress Protection (IP) Rating : IP67
  • Engine Make : Kohler - Lombardini
  • Engine Model : KD 441
  • Engine Horsepower : 8.2
  • Engine Power (kW) : 6.1
  • Engine Speed (RPM) : 3000
  • No. of Cylinders : 1
  • Emission Norms : CPCB-2
  • Fuel Tank Type : Bunded Tank
  • Fuel Tank Capacity : 80 Litres
  • Fuel Consumption (Approx.) : 1.0 Litres / h
  • Alternator Make : NSM Italy, Type: Single phase / 2 pole / brushless / Mc Avel / LINZ - Alumen
  • Rated Output : 5 kVA
  • Alternator Degree of Protection : IP23
  • Rating Voltage : 230 Volt
  • Auxiliary Power : 10 Amp (Maximum)
  • Type : Manual operation, winch and each operation interlocked
  • Maximum Height : 7.8 meters
  • No. of Mast Sections : 5
  • Mast Rotation : 359° with locking system & manual operation
  • Mast Erection Time : < 2 minutes
  • Wind Speed Stability : 110 Km / hr
  • L x W x H (Minimum) : 2000 x 1610 x 2410 mm
  • L x W x H (Maximum) : 2750 x 2970 x 7800 mm
  • Dimensions for Transport : 2010 x 1620 x 2420 mm
  • Weight : 665 kg (Approx.) Dry

Mobile Light Towers (VT Connect)

Introducing VT Connect: A fuel-efficient lighting solution with 4x productivity, saving one million annually. Lightweight, rain-protected design, and easy to handle. A main feature of the VT Connect is that up to four units can be connected in series to a single mother tower of VT-8 400W LED - Y3 to provide a large area of illumination without consuming additional fuel.

FEATURES

  • Great illumination with high power LED lamps
  • Easy to tow anywhere with 10" wheel
  • Easy to operate and handle
  • Designed to withstand the harshest conditions
  • Mast rotation of 359° with locking system
  • The mast can be easily extended and stowed using an easy-to-operate hand winch
  • Hard hood canopy and powder coating paint to prevent corrosion
  • Manual operation winch and each operation interlocked

SPECIFICATIONS

  • Type of Lamp Fittings : Rectangular
  • Floodlights / Lamp : LED
  • Wattage : 4 No’s × 190 / 200 W
  • Total Lumens Output : 100000 Lumens
  • Lumens per Watt : 100 LM / W
  • Light Coverage (Square Metres) : 2200 Sq m
  • Type : Manual operation winch and each operation interlocked
  • Maximum Height (Metres) : 5
  • Number of Mast Sections : 4
  • Mast Rotation : 359° with locking system & manual operation
  • Mast Erection Time : < 2 minutes
  • Wind Speed Stability : 100 Km / hr
  • L × W × H (Minimum) : 1240 × 800 × 2000 mm
  • L × W × H (Maximum) : 1670 × 1240 × 5100 mm
  • Dimensions for Transport : 1250 × 850 × 2100 mm
  • Weight : 280 kg (Approx.)

Mobile Light Towers (Nomadic LED)

VT-8 400W LED - Y3 lighting system has Yanmar Japan water cooled engine is designed with a bunded fuel tank, which helps to ensure the safe storage of fuel. It also features a manually operated winch with interlocked operations, which makes it easier for users during operations.

SPECIFICATIONS

  • Type of Lamp Fittings : Aluminium Oval
  • Floodlights / Lamp : Metal Halide
  • Wattage : 4 No’s × 1000 W MH
  • Total Lumens Output : 440000 Lumens
  • Lumens per Watt : 110 Lm / W
  • Light Coverage (Square Metres) : 20000 Sq m (Approx. 5 acres)
  • Engine Make : Yanmar, Japan
  • Engine Model : 3T NV80-IGE
  • Engine Horsepower : 11 (Continuous), 12 (Stand by)
  • Engine Power (kW) : 8.2 (Continuous), 9 (Stand by)
  • Engine Speed (RPM) : 1500
  • No. of Cylinders : 3
  • Emission Norms : CPCB-2
  • Fuel Tank Type : Bunded Tank
  • Fuel Tank Capacity : Up to 120 Litres
  • Fuel Consumption (Approx.) : 1.7 Litres / Hrs
  • Alternator Make : NSM / LINZ-Alumen / MC Alite Italy (Brushless)
  • Rated Output : 8 kVA
  • Alternator Degree of Protection : IP20
  • Rating Voltage : 230 Volt
  • Auxiliary Power : 16 Amp (Maximum)
  • Operation Type : Manual operation winch and each operation interlocked
  • Maximum Height : 8 Metres
  • Number of Mast Sections : 5
  • Mast Rotation : 359° with locking system & manual operation
  • Mast Erection Time : Less than 2 minutes
  • Wind Speed Stability : 110 Km / hr
  • L × W × H (Minimum) : 1700 × 1680 × 2500 mm
  • L × W × H (Maximum) : 2340 × 3060 × 7800 mm
  • Dimensions for Transport : 1710 × 1690 × 2510 mm
  • Weight : 780 Kg (Approx.)
